Today we’re going to do some oil-cooled maintenance.
Since the muffler was already off, removing the damper was really easy. The wear looked moderate.
I’ll apply NC100 grease so that even if micro-vibration occurs, the case side won’t wear down.
Using a later-model damper that isn’t the through-bolt type is necessary.
Let’s clean those hard-to-reach spots thoroughly—you only get the chance once in a while.
Let’s also clean those other hard-to-reach areas and apply rust preventative.
I’ll replace the generator damper. The area under the generator is another spot you only get to access once in a while.
If you rotate it back and forth, you can feel the play. It’s worn quite a bit.
When this damper wears down, it gets surprisingly noisy and rattly.
It was pretty stiff.
There’s no sprocket cover, and it’s a bit wet, so let’s replace the shift seal and the neutral switch O-ring.
It comes out easily with our special small sliding hammer.
Done.
I’ll remove this one too and replace its O-ring.
Let’s clean this hard-to-reach spot while we’re at it.
Number 9 is on there. You brought number 8, so let’s swap them.
Like everyone’s, the head cover gets pretty dirty from heat, oil, and mud.
Scrubbing it with a small brush at the wash station takes forever and doesn’t get it clean. With a big brush like this, we can blast away aggressively and get it spotless in no time.
I also cleaned up the muffler bracket while I was at it.
I make sure to clean around the bolts too, even if it’s just for show.
I also polished the right cover nicely.
I got so caught up in all this that I forgot to photograph inside the head cover. There was hardly any scoring though—it looked good.
I’m swapping the exhaust pipe bolts from stainless to iron. Rather than worry about galvanic corrosion or loosening, the real issue is that if they rust and seize, they’re a pain to remove. With iron bolts, even if they seize, the hole strips easily, which is a lifesaver.
I’ll sync the carburetors and we’re done.
It’s currently waiting for a test ride.
