Legendary? BIMOTA SB3 with GS1000 engine. Inspection. Deco-mainte. Shell Advance oil change

From here on, the work should proceed smoothly.
Signs of clearing the clogging are appearing (*´ω`*) hehe.

Now we’re moving forward with a plan to wrap things up quickly!

Decoboco’s other blog.
“RURAL GARAGE


A secret room for non-motorcycle stuff.
Convenient everyday items, relocation, delicious food, life philosophy and more.

←click

デイトナ(Daytona)
¥3,551 (2026/09/21 02:35時点 | Amazon調べ)
ヘンリービギンズ(Henly Begins)
¥7,920 (2026/09/21 07:35時点 | Amazon調べ)


If you’re not used to it, removing the fairing is a hassle.

We insert protective boards on both sides and drag it out.
Basically, you can’t remove it cleanly.
Without love, power, and trust with the owner, the work cannot be done.

We’re modifying the Deco-mainte content and proceeding.

Fork oil change that hasn’t been replaced in quite a while.
It’s a job that’s hard to request in terms of labor hours, but the effect is significant.
The smell and dirt look pretty good.

The inner tube has some minor damage.
For now there’s no leak, so we’ll keep using it. If it starts leaking, we’ll re-plate it.

Fork oil changed, vacuum bled, and air purged.
Structurally, this fork is tedious to bleed with just strokes, but vacuum bleeding does it in one go.
Using vacuum bleeding gives you peace of mind that any fork will be properly bled. It makes a huge difference once you adopt it.

Disassembling and cleaning the Keihin CR-SPL

It’s running fine, but I’m a bit concerned about the dirt.
We’ll do a light disassembly and freshen it up.

We don’t disassemble down to the four-stage, but we remove and clean the throttle valve, jets, and everything.
Checking the jets again will be good for the future.

The float chamber is rust-free and looks great.

A vacuum pump that can also be used for carburettor synchronization! Get one this year-end!

Engine oil is Shell Advance 4T Ultra

It was so clean we didn’t even need to change it….

Caliper cleaning and fluid change

Calipers with external dust seals are nice.
With a single oil seal, they have low friction and good operation while keeping dust out.
Both front and rear were problem-free.

The fluid condition is like this.
The rear looks pitch black, but that’s just the body’s aluminum anodizing showing through.
The brake fluid is absolutely reliable Golden Cruiser DOT4.

Brembo rear master 10.2926.00
It’s starting to weep a bit. It’s minor, so we’ll monitor it and consider alternatives.

Now we’ll reassemble and do a quick check, and we’re done!
