Service Request: Front and rear tire replacement + complete suspension conditioning
Machine Appeal: The 652cc air-cooled single-cylinder engine combined with belt drive creates lightweight yet intense piston pulses.
Key to Maintenance: Cleaning and rust-proofing the axle shaft during wheel removal, disassembling and cleaning the drum brake area, and adjusting belt drive tension. We ruthlessly eliminate rolling resistance (friction)!
Considering 20 years have passed, they’re in surprisingly good condition. I was a bit shocked… (´ー｀)
Removing the bearings to prepare the hub for wet blasting.
It’s been reborn like this~ Whee
Perhaps it’s because the hub is being pulled by the spokes. One side had the bearing press-fit clearance loosen, so we applied press-fit specific chemical to address it.
You can use a tire changer even with tubes. The worry about pinching the tube completely disappears, so tools really are essential.
They brought new ones, so we’re replacing them. By the way, the one I’m holding is a used one we wet-blasted (on the back side)
Nissin’s mysterious single-piston sliding caliper
It’s another mysterious caliper I’ve never seen before. It even has pad pins…
Considering the years and mileage, it was in surprisingly excellent condition for a non-anodized caliper.
We finished it off with a crisp wet blast.
Checking the piston diameter can lead to future reuse possibilities.
For a sliding caliper, smooth operation is everything. Replace the boots with new ones “silicone grease” for lubrication. Using mineral-based grease will cause swelling. When you balance silicone grease spray and grease well, it really moves smoothly. *This time the body side was a bit worn, so we had some trouble, but it’s better now.
Honestly… the pads on this caliper are likely to disappear… or so it seems. Is this representative model too maniacal, and only Suzuki has it?
Having pad pins with single-piston design bothers me—there’s an extra guide… Single-piston calipers from Nissin have a wide variety, so parts supply is reassuring.
The Savage 650 has extremely poor serviceability
True to the Savage 650. This bike has surprisingly poor serviceability.
Just to replace this battery case cover… You have to remove the seat, take off the side covers, lift the tank, shift the carburetor band, and barely squeeze in access. With so much empty space, I wish they’d made it simpler~
So the front end is now sharp and crisp! Next is getting the inspection certificate and we’re done (*´ω｀*)
Suzuki Savage 650 / LS650 (Rare air-cooled 652cc big-single cruiser).
Topic: Refreshing tires and chassis alignment for a smooth, friction-free ride. Details: Happy Saturday night from the Decoboco workshop! To kick off August, we worked on a truly unique classic—the Suzuki Savage 650. Featuring a massive 652cc single-cylinder engine and a clean belt-drive system, this lightweight cruiser delivers unmatched mechanical pulses. We replaced front and rear tires, thoroughly cleaned and greased the axle shafts, serviced the rear drum brake assembly, and calibrated the belt drive tension with absolute precision. Verdict: Removing mechanical drag transforms the riding experience. The bike rolls with effortless lightness, allowing the massive single-cylinder power to kick directly into the pavement. Keep your unique legends running smooth and sharp!
