“Surging in Popularity? Oil-Cooled” Inazuma 1200 Inspection Yoshimura ST-1 Cam Rear Disc 220φ Conversion Aluminum Torque Rod Swingarm OH Muffler Repainting

Finally! The Pivot Shaft Final Chapter?
It finally came out…(*´ω｀*)
Even if I kept hitting it, it shouldn’t have come out.

WellOnce you experience it, you shouldn’t be scared next time.
(´∀｀*)Hehe

Difficult delivery! The head came out but… still won’t budge even with hitting

Time passes….
To pull it out with hydraulics, I need a spacer. But there are limits to that too.
No matter how much I hit it, it won’t budge → I’ll do my best with hydraulics *Hydraulic stroke 12mm

BasicallyI make a spacer and can only pull out 12mm at a time.

But around 50-60mm, things changed completely.The hitting sound started working differently!
Knock♪Knock♪Knock♪(*’ω’*)Yay it came out!
It took so long~ I think wistfully.

Fused together by corrosion I’ve never experienced before

It feels a bit thicker to the touch…
The Inazuma 1200 and GS1200SShavepivot shafts that rust very easily.

The head seems to have plating, but what about the body part? I wonder…

Hmm~ awesome. Well, I was able to extract it safely without damaging the frame.

The bad feeling continues… Will the bearing come out…

Hmm….I just have toclean, lubricate, and heatand work on it.
The worst case scenario when pulling out the needle roller is“only the outer shell remains”.
If that happens, I can only grind it away bit by bit with a rotary tool, which is super tedious.

It was more normal than I thought(*´ω｀*)
Good, good~

I think wistfully about how amazing nature’s power is.

I’ll use a BITOR&D chromoly shaft (repurposed)

The inside of the swingarm pivot is full of rust

Since I love power tools, I finished it up with a Makita(*´ω｀*)
If I did it by hand, it would take forever to remove the rust.

First comes setup, second comes setup.
This way I can press it in nice and smoothly.

I’m replacing all the parts around the pivot with new ones.
The Suzuki genuine chain slider has made a comeback! Get yours while you can~

The hose guide has arrived too, so I’ll replace it

The original is riveted, so the hose can’t be detached.
I used Suzuki genuine 61196-38G01 to improve workability.

With this, I don’t need to remove rivets every time I take off the swingarm.
The freedom when maintaining the rear caliper also increases.

Once you experience it, you won’t be scared next time(*´ω｀*)

I always keep what I make stored away.
I don’t want to do it again, but once you experience it, you’re not scared anymore.
To be continued.
